Vertical Reefs of the Galápagos

D. Fornari - WHOI-MISO Facility - Alucia expedition AL1508, Dalio Exploration Trust

Expedition dates: September 18 – October 19, 2023
The Galápagos Islands are home to a dazzling array of cold-water corals. While they are understudied compared to the shallow-water corals, a subset of these deep-dwelling animals is even more shrouded in mystery—cold-water corals living on cliffs. The depth and inaccessibility of vertical corals to ship-based sensors present significant hurdles to studying these creatures. Chief Scientist Katleen Robert and her multidisciplinary team will overcome these challenges to map and characterize this extraordinary ecosystem while defining its environmental drivers. The team will deploy a number of advanced technologies including a laser scanner that will create an ultra-high resolution three-dimensional reconstruction of vertical cold-water coral reefs. As the Galápagos Islands are a protected area with little human impact,  its cliff-dwelling coral reefs likely represent these ecosystems in their pristine condition and can serve as a baseline for understanding change.

An Important Ecosystem in a Pristine Environment

The Galápagos Islands are a UNESCO World Heritage site, and the Galápagos Marine Reserve is one of the largest marine protected areas in the world. These protections, combined with the verticality of the cliffs, mean that these cold-water coral ecosystems have been untouched by trawling and other destructive activities. The near-pristine nature of the Marine Reserve will allow Chief Scientist Katleen Robert with Memorial University of Newfoundland and her team to study ideal and undisturbed ecosystems—vertical cold-water corals (CWC) as they “should” be—enabling the creation of baseline data to share with local colleagues for use in regional projects.

While tropical or shallow-water corals are more well-known and much more thoroughly studied, CWC constitutes roughly half the global population of corals. Living in depths between 50 and 6,000 meters, they are distributed widely across the Ocean. Vertical environments may be globally critical habitats for CWC, accounting for an estimated ~10% of surface area, but these remain mostly unexplored. This knowledge gap, especially pronounced in the southern hemisphere, makes this expedition essential in building a more balanced understanding of global corals.

Communities Forged by the Environment

CWC, long-lived but non-moving, are particularly sensitive to their environment. Lacking zooxanthellae, the symbiotic algae that provide energy to shallow-water coral, CWC instead feed on tiny organisms carried in passing currents. Once attached to cliff face, their immobility puts them at the mercy of these currents to support their colonies. Water column dynamics and the physical features of vertical reef surfaces shift and steer the current flow through the ecosystem. The effects of these interactions might create areas of scarcity or layers of nutrients that impact feeding conditions for CWC—their survival depends on it.

Unlike other CWCs, cliff-dwelling communities grow “out” rather than “up,” and this orientation might limit viable areas for coral colony expansion. The connection between the geology and the proliferation of CWC is another key piece to understanding the environmental conditions shaping these vertical reefs. The team will perform extensive analyses of collected samples to characterize and connect habitat geology to CWC.

The Laser Scanner—A Powerful Tool for Mapping

Robert and her team plan to build  a foundational map for connecting environmental drivers to habitat complexity, community composition, and biodiversity. It’s an ambitious map—an incredibly detailed 3-D reconstruction of the habitat that includes cliff morphology and additional layers of biological information. To meet this challenge, the team will adopt a technology not widely applied in studying these communities—ultra-high-resolution laser scanning. Like multibeam sonar, a commonly used mapping tool, a laser scanner creates a point cloud of data rather than visual imagery. Unlike multibeam, however, it can achieve an incredibly fine resolution—less than two millimeters.

Using ROV SuBastian as a survey vehicle, the team will map these vertical reefs to create accurate and immersive 3-D reconstructions of the environments. These maps will allow the team to understand the distribution and diversity of organisms while serving as a baseline for future surveys to reveal very fine-scale patterns like coral growth and the loss of individual polyps. Supplementary sampling, , and visual annotationwill precisely locate CWC in the point cloud, classify targets as living or dead, and identify individual species. Ultimately, the team will create an accessible digital reconstruction of cliff-dwelling coral ecosystems—a data visualization that allows everyone from scientists to second-graders to visit the deep sea.

Invaluable Insights to Shape the Future
The team’s work on this expedition—building the map, studying the reef-supporting substrate, and mapping how food-delivering currents swirl around the cliff faces—will hone their understanding of how CWC rely on and engage with their environment. Every organism is shaped by its surroundings, and studying one in an undisturbed setting is invaluable. The expedition will advance our knowledge of these understudied ecosystems while preserving a record of a healthy, functional vertical coral community—a useful tool in gauging human impact and shaping future conservation efforts.

D. Fornari - WHOI-MISO Facility - Alucia expedition AL1508, Dalio Exploration Trust DCIM118GOPROG0023268.
D. Fornari - WHOI-MISO Facility - Alucia expedition AL1508, Dalio Exploration Trust DCIM100GOPROG0021530.
Lower mesophotic coral ecosystems in the Coral Sea included steep walls dominated by azooxanthellate octocorals (fan corals - often called gorgonians).
Rock pinnacles with large Enallopsamia stony corals and an Oreo fish at approximately 600m depth on the flank of Orona Atoll.
Woods Hole Oceanographic Institution

Data & Publications

Trackline and Stations have been mapped on Google Earth

ADCP data, curated by University of Hawaii, can be accessed here.

All rock samples collected have been given International GeoSample Numbers (IGSN), which you can view here. You can access the sample data on SESAR here.

Raw data collected by R/V Falkor (too), including environmental sensor data is available at Rolling Deck to Repository.

Raw data from ROV SuBastian, sound velocity profile data, and raw backscatter and bathymetry data is available at MGDS.
