General Specifications
Length Overall | 82.90 meters |
Length between perpendiculars | 76.20 meters |
Beam, overall | 13.00 meters |
Freeboard | 2.28 meters |
Draft (design) | 4.80 meters |
Draft (gondola) | 5.80 meters |
Draft (air) | 24.00 meters |
Depth (moulded) | 6.67 meters |
Displacement (weight) | 2,260 m3 |
International Gross Tonnage | 2,024 GRT |
Net Tonnage | 608 NRT |
Fuel Capacity | 105,150 US gals / 398 m3 / 330 MT |
Fuel Consumption per day | at 10 kts 2,900 US gals / 11 m3 / 9.1 MT |
Galley Mess Seats | 30 |
Maximum Speed | 17 knots |
Cruising Speed | 10 to 12 knots |
Survey Speed | 8.0 knots |
Range at 10 kts | 8,000 nautical miles (estimated) |
Endurance with 44 personnel aboard | 36 days |
Year Built / Year Converted | 1981 / 2010-2012 |
Classification Society and Flag State
DNV-GL and Cayman Islands
Crew Complement
23 ship’s crew inclusive of marine technicians (total crew complement may vary depending on cruise requirements)
Berthing Accommodations for Scientists, Technical Personnel, and other Cruise Personnel
17 berths maximum. However, the total available number of berths available for the science party is dependent upon technical staffing required to operated ROVs, AUVs, workboats and 24-hour over-the-side operations (which can be up to eight additional personnel), Coastal State observers, and other cruise dependent personnel.
Main Engines and Generators
(2) main engines MWM TBD 5108 rated each at 2,941 kW @ 750 RPM, (2) main generators MTU 16V2000 rated each at 720 kW, (1) science generator MAN D2842 LE301 rated at 500 kW, (1) harbor / emergency generator MAN D2840 LE201 rated at 400 kW, (1) 50 Hz to 60 Hz converter Atlas for 100 kVA to provide 480 VAC 60 Hz, (1) 50 Hz to 60 Hz converter Atlas for 25 kVA to provide clean power
Dynamic Positioning
EMRI Joystick / DP system with ROV following mode for launch, deploy and following for distances up to 150 meters at 2 knots.
Rudders
Becker Marine System flap rudders with linked operation (do not move independently of one another) and operated at maximum +/- 35 degrees
Bow Thruster
(1) Tunnel Thruster, 536 hp / 340 kW
